Hyundai Equus: Turn signals and lane change signals - Lighting - Features of your vehicle - Hyundai Equus 2009-2024 Owners ManualHyundai Equus: Turn signals and lane change signals

The ignition switch must be on for the turn signals to function. To turn on the


The ignition switch must be on for the turn signals to function. To turn on the turn signals, move the lever up or down (A). Green arrow indicators on the instrument panel indicate which turn signal is operating. They will self-cancel after a turn is completed. If the indicator continues to flash after a turn, manually return the lever to the OFF position.

To signal a lane change, move the turn signal lever slightly and hold it in position (B). The lever will return to the OFF position when released.

If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.

One-touch triple turn signal

To activate an one-touch triple turn signal move the turn signal lever slightly for less than 1.8 seconds and then release it. The lane change signals will blink 3 times.

You can activate or deactivate this feature. Refer to “User Settings” in this section.

✽ NOTICE

If an indicator flash is abnormally quick or slow, a bulb may be burned out or have a poor electrical connection in the circuit.

    High beam operation
    To turn on the high beam headlights, push the lever away from you. Pull it back for low beams. The high beam indicator will light when the headlamp high beams are switched on. To prevent the ...

    Front fog light
    Fog lights are used to provide improved visibility and avoid accidents when visibility is poor due to fog, rain or snow etc. The fog lights will turn on when fog light switch (1) is turned to ...
