Underdrive Brake Control Solenoid Valve(UD/B_VFS) Specifications
Specifications
Direct control VFS[UD/C]
x Control type : Normal low type
Control Pressure kpa (kgf/cmx, psi)0~1569.06 (0~16,0~227.57)Current value(mA)0~1100 Internal resistance ...
Schematic Diagrams
ESP Circuit Diagram
ESP Connector Input/Output
[Standard]
[Premium]
Connector TerminalSpecificationPin NoDescriptionStandardPremium2931IGNITION1(+)High level of wake up voltage : 4.5V < ...
Power Mosfet Repair procedures
Inspection
1.
Turn the ignition switch ON.
2.
Manually operate the control switch and measure the voltage of the blower motor.
3.
Select the control switch to raise the voltage until high ...
