Hyundai Equus: Front Hub / Knuckle / Tone Wheel Components and Components Location - Front Axle Assembly - Driveshaft and axle - Hyundai Equus VI 2009-2022 Service ManualHyundai Equus: Front Hub / Knuckle / Tone Wheel Components and Components Location

Second generation VI (2009Ц2022) / Hyundai Equus VI 2009-2022 Service Manual / Driveshaft and axle / Front Axle Assembly / Front Hub / Knuckle / Tone Wheel Components and Components Location

Component location

1. Front knuckle assembly
2. Hub assembly
3. Dust cover
4. Brake disc
